Mitsui S200MA Roadheader — 1000V Flameproof, Underground Coal (Enquire)

Overview

Mitsui S200MA roadheader with pineapple cutting head, configured 1000/1100V flameproof for underground coal operations. Suitable for development and roadway drivage in underground coal mines throughout Australia. Offered for sale by CMS — requires AS3800 and minor mechanical work to put into production.

Machine Specifications

• Cutting motor: 200/110 kW — 4/8p
• Hydraulic motor: 110 kW — 4p
• Drum revolution: 46/23 rpm (50Hz) · 55/28 rpm (60Hz)
• Cutting range: 5.1m height × 6.3m width
• Gathering arm revolution: 30/36 rpm (50/60Hz)
• Loading capacity: 7 m³/min (max)
• 1st conveyor speed: 36/43 m/min (50/60Hz)
• 2nd conveyor speed: 61/73 m/min (50/60Hz)
• 2nd conveyor motor: 5.5 kW — 4p
• Travelling speed: 7.5/9.0 m/min (50/60Hz)
• Climbing angle: + or −15°
• Hydraulic pump: Rexroth
• Rated pressure: 210 MPa
• Oil tank capacity: 600 L
• Supply voltage: 1000/1100V — 50/60Hz (flameproof)

Dimensions & Weight

• Total weight: 55 tonne
• Total length: 15.6 m
• Total width: 3.6 – 4.8 m
• Total height: 2.3 m
• Contact pressure: 0.13 MPa

Key Features

• 1000/1100V flameproof (Ex) rating — compliant for underground coal environments
• Pineapple-type cutting head for efficient rock and coal cutting
• Integrated spinners and twin-conveyor loading system
• Crawler-mounted, articulated, with ±15° climbing capability
• Suited to Australian underground coal development and roadway drivage

Condition

Workshop maintained and well presented, AS3800 and minor mechanical work to put into production.. Full condition report and service history available to qualified buyers on enquiry. Inspection by appointment, arranged through CMS Corequip.

Location & Delivery

Located in Australia. Delivery / float transport can be arranged and quoted separately to buyer's site. Sold as-is, where-is.

How to Enquire

Use the Enquire Now button above to register your interest. Include your company, ABN, intended application, timing, and budget. We'll respond with the condition report, inspection options, and pricing.

About CMS Corequip

CMS Corequip is the equipment and consumables arm of CMS Asia Pacific Pty Ltd, with over 20 years in Australian underground mining, tunnelling and electrical. This machine is offered directly by CMS. GST invoicing, ABN quoted.

Listing reference: MCH-RHD-0002-U
